V12 Anti-vandal Switch for Zn-Al Alloy Material and Round
These long life IP65 waterproof push button switches have solder lug or screw terminal options, and are 1-pole, momentary switches with an IP65 rating for protection...
These long life IP65 waterproof push button switches have solder lug or screw terminal options, and are 1-pole, momentary switches with an IP65 rating for protection against dust and moisture. They fit in a panel cutout sized 12mm with a maximum depth of 5mm.
V12 Series Long Life IP65 Waterproof Push Button Switch
The V12 Series long-life IP65 waterproof push button switch features an IP65 rating for protection against dust and moisture. It offers a domed actuator with multiple color options including black, white, yellow, blue, green, red, nickel, and stainless steel.
The V12 series IP65 waterproof push button switch has an electrical rating of 2A, 36VDC and has an electrical life expectancy of 200,000 cycles. Multiple actuator finish options are available, including a black anodized finish.
These long-life IP65 switches come with single-pole circuits and screw or solder lug termination options.
They are meant for mounting in a panel cutout sized 12mm in diameter.
- IP65 rated protection against dust and moisture
- Solder lug or screw terminal options available
- 1 pole; momentary pushbuttons
Applications for this anti-vandal switch include:
- Kiosks and ticket dispensers
- Industrial controls
- Medical equipment
- Electrical housewares
- Audio/visual
- Security devices
Functions
Order Code
Technical Data
| Type | V12-B-S | V12-B-N | V12-B-A | |
| Actuator Options | Round | |||
| Function | Momentary 1no | |||
| Specification | 0.6kgs/box | |||
| Number of Switch | Single Control Switch | |||
| Certification | ISO9001, CE, CCC, RoHS, Reach | |||
| Usage | Control Button, Start Button, Reset Button, Control Switch | |||
| Max. Panel Thickness: | 0.236″ (6.0mm) | |||
| Terminal | Screw / Solder lug (2.8 x 0.5) | |||
| Max. Switch Rating | 2A/ 48VDC | |||
| Contact Resistance | ≤50mΩ | |||
| Insulation Resistance | ≥1000mΩ | |||
| Dielectric Strengh | 2000VAC | |||
| Operation Temp. | -20°C ~ +55°C | |||
| Transport Package | 50PCS/Box | |||
| Mechanical Life | >1,000,000cycles | |||
| Electrical Life | >200,000cycles | |||
| Torque | 5 ~ 14Nm | |||
| Operation Pressure | ~3.5N | |||
| Operating Stroke | ~2.5mm | |||
| Protection | IP65 | |||
| Material | Contact | Silver Alloy | ||
| Actuator | Stainless Steel/ Brass/ PBT | |||
| Body | Stainless steel | Nickel plated brass | Zin-Al Alloy | |
| Base | PBT | |||
| Color | Actuator |

|
||
Descriptions/ Panel Cutout
Dimension
Solder terminal
Screw terminal
Solder lug or screw terminal options available
1 pole; momentary pushbuttons
On the product detail page of every series you will find information about the switch. If it is washable or sealed to a certain IP rating, it will list it on the product detail page. To get to the product detail page, go to our product catalog and search by type or by feature.
It is a safe assumption to note that all Langir switches comply with EN 60529.
It is a safe assumption to note that all our switches comply with RoHS standards. You can find our complete library of RoHS certifications by part number, Certifications.
We have solder profile recommendations for hand soldering, SMT reflow and wave soldering processes. You can find our recommendations Soldering Profiles.
Help can be given either over the phone by sending the fix parts to you, or we will requires you to send products back to us for fixing.
Water-Wash, Process-Sealed, IP67 Switch Seal Rating
Definition of IP Codes (Ingress Protection):
IEC (International Electrotechnical Commission) 60529 Standards document specifies an international Classification system for the sealing effectiveness of enclosures of electrical equipment against the “Intrusion into the equipment of foreign bodies and moisture”.
1. Degrees of Protection – First Digit
6 Dust-tight
2. Degrees of Protection – Second Digit
7 Protection against effects of immersion from 15cm to 1m (6″ to 40″).
Based on the above, our standard for defining a “process-sealed” switch is “sealed to meet the minimum requirements of IP-67”. This means that a switch rated to IP-67 is “Dust-tight” and will pass a water submersion test at 40″ (1m), for up to 30 minutes.
Due to the variables encountered in actual water-wash machine processing, IP67 does not necessarily insure that water entry into the switch cannot occur. the water-wash pressures and air-knife drying that occurs in modern pcb machine-washing can exceed the seal requirements of the IP-67 rating.
